Briggs & Stratton 25V332-0006-F1 Horizontal Engine for SALE
$ 638,00
Brand: Briggs & Stratton EnginesThe Briggs & Stratton 25V332-0006-F1 Horizontal Engine delivers 14 gross HP from its 408cc OHV design. It features recoil starting, cyclonic air filtration, TransportGuard controls, a flush-mounted muffler and a 1-inch by 3-31/64-inch keyed crankshaft.
Briggs & Stratton 25V332-0006-F1 Horizontal Engine
The Briggs & Stratton 25V332-0006-F1 Vanguard 400 is a commercial-grade horizontal-shaft engine engineered for construction equipment, generators, pumps, pressure washers, tillers and demanding rental applications. Its 408cc single-cylinder OHV design produces 14 gross horsepower at up to 3,600 RPM, delivering dependable power and strong load response.
Key Features
- Commercial-grade Vanguard 400 engine
- 408cc single-cylinder OHV design
- Rated at 14 gross horsepower
- Recoil starting system
- Reliable cold-weather starting
- Integrated cyclonic air filtration
- Advanced Nano filter media with AutoShed technology
- Air-filter service intervals up to 600 hours
- TransportGuard three-in-one control system
- CDI electronic ignition
- One-inch keyed horizontal crankshaft
- Flush-mounted muffler included
- EPA-compliant engine design
Specifications
| Specification | Details |
|---|---|
| Brand | Briggs & Stratton |
| Model | 25V332-0006-F1 |
| Series | Vanguard 400 |
| Engine type | Single-cylinder, four-stroke OHV |
| Shaft orientation | Horizontal |
| Displacement | 408cc |
| Gross horsepower | 14 HP |
| Maximum speed | 3,600 RPM |
| Starting system | Recoil |
| Crankshaft diameter | 1 in. |
| Crankshaft length | 3-31/64 in. |
| Keyway | 1/4 in. |
| Crankshaft end | Drilled and tapped 7/16-20 |
| Bore | 3.46 in. |
| Stroke | 2.64 in. |
| Compression ratio | 8.3:1 |
| Ignition | CDI electronic ignition |
| Lubrication | Splash lubrication |
| Oil capacity | 32 fl. oz. |
| Air cleaner | Integrated cyclonic air cleaner |
| Filter media | Nano media with AutoShed technology |
| Engine controls | TransportGuard three-in-one control |
| Muffler | Flush-mounted muffler included |
| Fuel type | Gasoline |
| Approximate dimensions | 14.3 × 17.9 × 18.1 in. |
| Listed product weight | Approximately 93 lb. |
| EPA compliant | Yes |
