Briggs & Stratton 613477-0278-J1 Horizontal Vanguard Engine for SALE
$ 2.033,90
Brand: Briggs & Stratton EnginesBuy the Briggs & Stratton 613477-0278-J1 Horizontal Vanguard Engine with a 1-7/16-inch shaft, electric start and 20A charging.
Briggs & Stratton 613477-0278-J1 Horizontal Vanguard Engine
The Briggs & Stratton 613477-0278-J1 Vanguard Engine delivers dependable commercial power for compatible construction machinery, pumps, compressors and other heavy-duty equipment. Its 993cc Big Block OHV V-Twin configuration provides 35 gross HP with smooth operation and reliable load-handling performance.
Key Features
- 35 gross HP output
- 993cc Vanguard Big Block V-Twin
- Horizontal PTO shaft
- Heavy-duty 1-7/16-inch crankshaft
- Electric starting system
- 20-amp charging system
- Heavy cast-iron flywheel
- Integrated oil cooler
- Centrally located oil pump
- Full-pressure lubrication
- Replaceable spin-on oil filter
- Dura-Bore cast-iron cylinder sleeves
- Engine-mounted fuel pump
- Air-cooled OHV construction
- EPA-compliant configuration
Specifications
| Specification | Details |
|---|---|
| Brand | Briggs & Stratton |
| Series | Vanguard Big Block |
| Model | 613477-0278-J1 |
| Engine Type | Four-stroke OHV V-Twin |
| Gross Horsepower | 35 HP |
| Displacement | 993cc |
| Shaft Orientation | Horizontal |
| Fuel Type | Gasoline |
| Fuel Delivery | Carburetor with fuel pump |
| Starting System | Electric start |
| Charging System | 20 amp |
| Maximum Engine Speed | 3,800 RPM |
| Bore | 3.37 in |
| Stroke | 3.41 in |
| Compression Ratio | 8.2:1 |
| Crankshaft Type | Straight, keyed |
| Crankshaft Diameter | 1-7/16 in |
| Crankshaft Length | 4-1/2 in |
| Crankshaft Keyway | 3/8 in |
| Drilled and Tapped End | 5/8-18 |
| Cylinder Configuration | V-Twin |
| Cylinder Sleeves | Dura-Bore cast iron |
| Flywheel | Heavy cast iron |
| Cooling System | Air cooled |
| Lubrication System | Full pressure |
| Oil Filter | Spin-on filter |
| Oil Cooler | Included |
| Oil Capacity | 79 fl oz |
| Metric Oil Capacity | Approximately 2.34 L |
| Fuel Pump | Included |
| Fuel Tank | Not included |
| Muffler | Not included |
| Commercial Warranty | Three-year limited |
| Recommended Application | Compatible commercial and industrial equipment |
