Honda GX120 SJD2 Horizontal OHV Engine for SALE
$ 343,20
Brand: Honda EnginesBuy the Honda GX120 SJD2 horizontal OHV engine with 118cc power, recoil start and an 18mm keyed shaft for compatible commercial reel mowers.
Honda GX120 SJD2 Horizontal OHV Engine
The Honda GX120 SJD2 Horizontal OHV Engine is a compact commercial engine designed primarily for reel mowers and professional golf-course maintenance equipment. Its air-cooled 118cc four-stroke OHV design produces 3.5 net horsepower at 3,600 rpm and 5.4 lb-ft of torque at 2,500 rpm, delivering dependable performance with efficient fuel consumption.
Key Features
- Commercial-grade Honda GX120 construction
- 118cc air-cooled four-stroke OHV engine
- 3.5 net HP at 3,600 rpm
- 18mm × 1.97″ straight keyed crankshaft
- Heavy-duty recoil starting system
- Automatic mechanical decompression
- Standard exhaust muffler
- Mechanical governor
- Compact 28.9-pound design
- Ideal for professional reel mowers
Specifications
| Specification | Details |
|---|---|
| Engine model | Honda GX120 SJD2 |
| Engine family | GX120 |
| Engine type | Air-cooled, four-stroke OHV |
| Cylinders | Single cylinder |
| Displacement | 118cc |
| Net power | 3.5 HP at 3,600 rpm |
| Net torque | 5.4 lb-ft at 2,500 rpm |
| Bore × stroke | 60 × 42 mm |
| Compression ratio | 8.5:1 |
| Shaft orientation | Horizontal |
| Crankshaft type | Straight keyed |
| Shaft diameter | 18mm |
| Shaft length | 1.97 inches |
| Starting system | Recoil |
| Ignition system | Transistorized magneto |
| Carburetor | Butterfly type |
| Governor | Mechanical |
| Muffler | Standard |
| Oil capacity | 0.59 US qt |
| Fuel capacity | 2.1 US qt |
| Recommended fuel | Unleaded gasoline, 86 octane or higher |
| Dry weight | Approximately 28.9 lb |
