B&G Vulcan 7R Chartplotter for SALE
$ 500.00
Brand: B&GBuy the B&G Vulcan 7R Chartplotter with a bright 7-inch touchscreen, 10Hz GPS, SailSteer, Wi-Fi, NMEA 2000 and autopilot compatibility.
B&G Vulcan 7R Chartplotter
The B&G Vulcan 7R Chartplotter is a compact sailing navigation display designed for coastal cruising and club racing. Its bright 7-inch multi-touch screen provides intuitive control using familiar tap, swipe, and pinch-to-zoom gestures, making charts, routes, and sailing information easy to access—even in challenging conditions.
Purpose-built sailing functions such as SailSteer, Laylines, SailingTime, and RacePanel display essential wind, tide, speed, heading, waypoint, and race-start information clearly. A built-in 10Hz GPS receiver delivers fast and accurate positioning, while integrated Wi-Fi makes software updates and device connectivity more convenient.
Connect the Vulcan 7R to a compatible NMEA 2000 network to display instrument data and control a B&G autopilot. The chartplotter is also ready for Broadband Radar, ForwardScan, CHIRP sonar, and DownScan Imaging when used with compatible accessories and transducers.
With an IPX6/IPX7 waterproof rating and flexible bracket or panel mounting, the B&G Vulcan 7R provides a dependable navigation center for modern sailing vessels.
Key Features
- Bright 7-inch multi-touch display
- 800 × 480-pixel resolution and 1,200-nit brightness
- Built-in high-accuracy 10Hz GPS
- SailSteer, Laylines, SailingTime, and RacePanel
- Integrated Wi-Fi and Bluetooth
- NMEA 2000 connectivity
- B&G autopilot control capability
- Broadband Radar and ForwardScan ready
- Integrated CHIRP, DownScan, and ForwardScan support
- Compatible with C-MAP, Navionics, Insight, and NV Digital charts
- Bracket or flush-panel mounting
- IPX6 and IPX7 waterproof protection
- Two-year manufacturer warranty
Technical Specifications
| Specification | Details |
|---|---|
| Display size | 7 inches |
| Display resolution | 800 × 480 pixels |
| Screen brightness | 1,200 nits |
| GPS | Internal 10Hz, 32-channel receiver |
| Position accuracy | Approximately 3 meters |
| Networking | NMEA 2000, Ethernet, Wi-Fi and Bluetooth |
| Card slot | 1 × microSD |
| Sonar compatibility | CHIRP, DownScan and ForwardScan |
| Supply voltage | 12V DC (10–17V) |
| Typical power consumption | 12W |
| Waterproof rating | IPX6/IPX7 |
| Dimensions | 197 × 141 × 82.7 mm |
| Weight | 1.32 kg |
| Mounting | Bracket or panel mount |
| Manufacturer SKU | 000-14082-001 |
