B&G Zeus S 12 Chartplotter
Simplify navigation and manage your complete sailing system with the B&G Zeus S 12 Chartplotter. Its large, high-definition touchscreen provides generous space for charts, radar, instruments, sonar and sailing data, making it ideal for larger cruising and racing yachts.
The 12-inch SolarMAX IPS display delivers a sharp 1280 × 800 resolution, 1,200-nit brightness and wide viewing angles. Charts and navigation data remain clearly visible in direct sunlight and through polarized sunglasses.
An intuitive interface, customizable screen layouts and guided Setup Wizard make the Zeus S easy to configure and operate.
Dedicated Sailing Modes
Zeus S presents the information most relevant to the current activity:
- Cruise Mode: Prioritizes charts, routes and essential cruising information.
- Race Mode: Provides quick access to StartLine, race routes, timers and performance data.
- Anchor Mode: Displays information useful for monitoring the boat while anchored.
- Night Mode: Reduces glare and improves visibility during low-light navigation.
Advanced Sailing Features
The Zeus S 12 includes enhanced B&G sailing tools for cruising and racing:
- SailSteer: Combines wind, heading, tide, layline and waypoint information in one visual display.
- Laylines: Shows predicted tacking and gybing routes directly over the chart.
- StartLine: Displays time, distance and vessel position relative to the racing start line.
- SailingTime: Calculates realistic arrival times when sailing a route that requires tacking.
- Routes and racing tools: Simplify race-course entry, waypoint management and performance monitoring.
- C-MAP Safety Alerts: Warn of shallow water and dangerous charted objects along the vessel’s course.
Compatible wind, depth, speed and heading sensors may be required to use all sailing calculations.
C-MAP DISCOVER X Cartography
The US model includes a C-MAP DISCOVER X North America chart card. DISCOVER X provides clear marine cartography and useful navigation features, including:
- Detailed coastal and inland-water coverage
- High-resolution bathymetric contours
- Custom Depth Shading
- Tides and currents
- Harbor information and points of interest
- Fast autorouting
- C-MAP Safety Alerts
- Simplified chart management and updates
The Zeus S 12 also supports optional C-MAP REVEAL X charts for additional premium cartographic features such as shaded relief and satellite imagery where available.
Integrated Sonar Capability
A built-in 9-pin XSONIC sonar port supports compatible transducers without requiring a separate basic sonar module. Supported technologies include single-channel CHIRP, traditional 50/200 kHz sonar, HDI and Active Imaging.
A sonar transducer is not included with this package.
Complete Marine-System Integration
NMEA 2000, Ethernet, Wi-Fi and Bluetooth connectivity allow the Zeus S 12 to function as the center of an integrated sailing system. Connect compatible B&G HALO radar, autopilots, AIS equipment, Triton² and Nemesis instruments, Triton Edge sailing processors and vessel sensors.
IP-camera support provides additional onboard visibility, while B&G App integration supports route planning, waypoint management, chart access and software updates.
Key Features
- Large 12-inch SolarMAX IPS touchscreen
- 1280 × 800-pixel display resolution
- 1,200-nit sunlight-viewable screen
- Wide 85-degree viewing angles
- Readable through polarized sunglasses
- C-MAP DISCOVER X North America charts included
- Cruise, Race and Anchor sailing modes
- Dedicated low-light Night Mode
- SailSteer and Laylines
- StartLine and advanced racing tools
- C-MAP-powered Safety Alerts
- Fast autorouting with compatible charts
- Integrated 10 Hz GPS receiver
- Built-in 9-pin XSONIC 1 kW sonar port
- CHIRP, HDI and Active Imaging support
- Compatible with B&G HALO radar
- Integrated B&G autopilot control
- Triton², Nemesis and Triton Edge compatibility
- AIS-data display through compatible equipment
- NMEA 2000 and Ethernet networking
- Integrated Wi-Fi and Bluetooth
- B&G App integration
- USB-A and microSD connectivity
- IP-video camera support
- Guided Setup Wizard
- Bracket, panel or flush mounting
- IPX6 and IPX7 water resistance
Technical Specifications
| Specification | Details |
|---|---|
| Brand | B&G |
| Model | Zeus S 12 |
| US manufacturer part number | 000-15224-001 |
| Global-basemap part number | 000-15225-001 |
| Product type | Sailing chartplotter and multifunction display |
| Display size | 12 inches |
| Display type | SolarMAX IPS multi-touch |
| Display resolution | 1280 × 800 pixels |
| Screen brightness | 1,200 nits |
| Viewing angles | 85° top, bottom, left and right |
| Included cartography | C-MAP DISCOVER X North America—US model |
| Supported charts | C-MAP DISCOVER X and REVEAL X |
| GPS | Integrated 10 Hz, 32-channel receiver |
| Position accuracy | Approximately 3 meters under suitable conditions |
| Sailing modes | Cruise, Race, Anchor and Night |
| Sailing features | SailSteer, Laylines, StartLine and SailingTime |
| Sonar port | One 9-pin XSONIC port, up to 1 kW |
| Sonar compatibility | Single-channel CHIRP, 50/200 kHz, HDI and Active Imaging |
| Radar compatibility | Compatible B&G HALO radar systems |
| AIS | Receives AIS information over NMEA 2000 |
| Autopilot compatibility | NAC-1, NAC-2, NAC-3, NAC-D and H5000 |
| Networking | NMEA 2000 and Ethernet |
| Wireless connectivity | Wi-Fi and Bluetooth 4.0 |
| External storage | One microSD slot |
| USB | One USB-A port |
| Video | IP-camera support |
| Waypoint capacity | Up to 6,000 |
| Route capacity | Up to 500 |
| Track capacity | Up to 50 |
| Supply voltage | 12 V DC; 10–17 V operating range |
| Maximum power consumption | 29.7 W |
| Recommended fuse | 3 A |
| Water resistance | IPX6/IPX7 |
| Dimensions without bracket | Approximately 12.2 × 8.2 × 3.1 inches |
| Dimensions with bracket | Approximately 12.58 × 8.46 × 3.38 inches |
| Weight | Approximately 4.9 lb |
| Mounting | Bracket, panel or flush mount |
| Warranty | Two years |
Package Contents
The US package typically includes:
- B&G Zeus S 12 chartplotter
- C-MAP DISCOVER X North America chart card
- Four-pin power cable
- Fuse kit
- U-shaped mounting bracket
- Panel-mounting hardware
- Corner clips
- Sun cover
- Installation documentation
Radar, sonar transducer, NMEA 2000 starter kit, AIS and sailing sensors are sold separately unless explicitly included by the retailer.
